Swivel Ring Flange Application Data Sheet

Form: TTF-40-005 R1

Email: ttaftermarket@sypris.com

Address: 2612 Howard Street, Louisville, KY 40211

Phone: +1 502-774-6011

Fax: +1 502-774-6300

Basic Information

Date *

Your Reference No.

Company *

Contact Info. *

Email *

Telephone *

Project Name

End Use Location

Quantity

Flange Size (NPS)

Flange Class

Flange Spec for Dims ¹

Matching Wall Thickness

Matching Wall Grade ²

Design Pressure

Design Temperature

Gasket Surface

Pressure Part Mat'l Cert.

Contents of Pipe

Special Req.: (NDE, Origin, Special Content, etc.)

Notes:

ASME 16.5 for 24" and smaller or ASME 16.47 Series "A" or "B" for 26" and larger.
Material and Yield strength of component/equipment that SRF will be welded to.
